Form parameters | ||
Mode | Name and Description | Internal PoE IP PTZ Camera 2MP with SMD IR 100M night version |
ASRIH498-020-56P | ||
Camera | Image Sensor | 1/2.8" 2.0 Mpixes CMOS Sensor,His3516Ev300+GC4653 |
Effective Pixels | 2.0 Megapixels | |
Min. Illumination | Color: 0.1lux, B/W:0.01lux. | |
Zoom | 20X optical , f=4.7mm~94mm(F1.6 to F2.7) Software 30X | |
Day/Night | Auto ICR | |
WDR | Digital WDR | |
OSD Display | Time, Camera Name | |
IR | Luminary | 8 PCS Infrared lights |
Night vision distance | 100m | |
Lamp control | CDS Control | |
Network | Video Compression | H.265/H.264/MJPEG |
Streams | Dual streams | |
Frame Rate | Main stream: 1920*1080, (1-15fps) 1280*720,720*576,720*480,640*480; (1-16fps) | |
Sub-stream:640*480,480*360,352*288,320*240,176*144; (1-16fps) | ||
MJPEG: 1920*1080,1280*720 | ||
Bitrate | CBR/VBR, bitrate:128Kbps~10000Kbps variable | |
Audio Compression | G711A, G711U, G.726 | |
P2P | Android、IOS | |
Protocols | TCP/IP,HTTP,NTP,IGMP,DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,HTTPS,P2P | |
Motion detect | Support | |
Privacy Zone Masking | Support | |
Onvif | Onvif 2.4 | |
Network | 10/100M Base-TX Ethernet, RJ45 Connector | |
POE | Support | |
Wifi | N/A | |
Mini SD Card | N/A | |
Alarm I/O | N/A | |
Audio I/O | Support Audio in+DC out for Microphone | |
Reset Button | N/A | |
Dome Features | CPU Type | 32 bit ARM CPU |
Address | 0~255 | |
Pan Range | 360° | |
Tilt Range | -5~90° | |
Manual pan speed | 0.05-100º/S | |
Manual tilt speed | 0.05-100º/S | |
Preset points | 256 | |
Patrol scan | 4 | |
L/R Scan | 1 | |
Horizontal Scan | 1 | |
Power-off memory | Support | |
General | Work temperature | –20℃~60℃ |
Work Humidity | 0%~90% (Non condensing) | |
Power | POE & DC12V±10%; 4A | |
Consumption | <15W | |
Weight | 2.35kg |
