| Mode | Name and Description | H.265 2.0MP HD Starlight Full Color IP IR High Speed Dome Camera |
| ASRIH692-033-3692 | ||
| Camera | Image Sensor | 1/2.8” 2.0MPixel SONY IMX222 |
| Effective Pixels | 2.0 Mpixes | |
| Min. Illumination | Color：0.2Lux@(F1.2, AGC ON) B/W: 0.02Lux@(F1.2, AGC ON) | |
| Zoom | 33X , f=4.2mm~152mm, D/N( ICR-Cut) ,F1.6~F3.0 | |
| Day/Night | Day / Night / External control（IR Cut Filter） | |
| SNR | ≥50dB(AGC OFF) | |
| WDR | Digital WDR，≥120dB | |
| AGC | Auto / Manual | |
| White balance | Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp | |
| Digital noise Reduction | DNR,3DNR | |
| Shutter speed | 1/5~1/50000 | |
| Network | Video Compression | H.264 Main Profile/M-JPEG |
| Streams | Dual streams | |
| Frame Rate | Main stream: | |
| 1920*1080, 1-25(30)fps; 1280*720, 1-25(30)fps | ||
| Sub-stream: | ||
| 480*640, 1-25(30)fps; 480 *360 1-25(30fps 352*288, 1-25(30)fps; 176*144, 1-25(30)fps | ||
| MJPEG: | ||
| 1920*1080, 1280*720, Close | ||
| Bitrate | CBR/VBR, bitrate：32Kbps~16Mbps variable | |
| Audio Compression | G711，PCM | |
| P2P | Android、IOS | |
| Protocols | TCP/IP/HTTP/DHCP/DNS/DDNS/RTP/RTSP/PPPoE/SMTP/NTP/UPnP/ONVIF | |
| Motion detect | Support | |
| Privacy Zone Masking | Support | |
| Onvif | Onvif 2.4 | |
| Network | 10/100M Base-TX Ethernet, RJ45 Connector | |
| Mini SD Card | Up to 64GB(Optional) | |
| Alarm I/O | 1/1(Optional) | |
| Audio I/O | 1 input (Linear level, Resistance: 1000 Ohm); 1 output (Linear level, Resistance: 600 Ohm); | |
| IR | Luminary | Array Φ20 8pcs |
| Night vision distance | 120M | |
| Lamp control | Auto, Manual, by Zoom | |
| Dome Features | CPU Type | 32 bit ARM CPU |
| Address | 0~255(soft address and hard address) | |
| Pan Range | 360° continued rotation | |
| Tilt Range | 0~90°(Auto Flip) | |
| Manual pan speed | 0~240º/S | |
| Manual tilt speed | 0~120°/S | |
| Preset speed | 400°/S | |
| Actual preset Accuracy | ±0.10° | |
| Preset points | 255 | |
| Other function | 8 Tour, Intelligent Three dimensional Scan, 8Pattern group ,Operation recall, Manual continued Auto Scan | |
| Intelligent power off real time memory |
automatic save functions setting ,automatic wake up tour function | |
| General | Work temperature | External–35℃~55℃ |
| Work Humidity | 0%~90% (Non condensing) | |
| Power | DC12V±10%; 5A | |
| Consumption | < 50W |
